Connecting the Fiber-Optic Cables
ServerNet Cluster 6780 Planning and Installation Guide—527301-005
6-21
Task 5: Connect a Cable to the Node
Figure 6-7 shows the effect of uneven fiber insertion.
Figure 6-6. Inserting a Fiber-Optic Cable Connector Into an MSEB Receptacle
Figure 6-7. Effect of Uneven Fiber Insertion on Link Alive
055CDT .CDD
Keys on Connector Body
VST145.vsd
TxRx
Fibers
Not
Evenly
Inserted
TxRx
Link
Alive
TxRx
Fibers
Evenly
Inserted
Defective ConnectorsGood Connector
Link
Alive
No Link
Alive
