Checking Operations
ServerNet Cluster 6780 Planning and Installation Guide—527301-005
8-4
Checking for Problems Between Nodes
Checking for Problems Between Nodes
Use SCF to check that direct ServerNet communication is possible on both fabrics
between all nodes in the ServerNet cluster. This command queries the SNETMON
processes in all nodes and displays any connectivity problems. You do not have to
issue separate commands for each node.
1. Log on to a node:
-> STATUS SUBNET $ZZSCL, PROBLEMS
2. For each connection that should be active, verify that the display shows:
No connectivity problems detected.
3. If a displays shows a problem with connectivity to a node or nodes, refer to
Restoring Connectivity to a Node on page 10-7.
Checking the Operation of Each Switch
Perform these procedures after you install, migrate, or replace any of the specified
hardware and software:
•
Checking the Power to Each Switch on page 8-5
•
Checking the Switch Components on page 8-5
•
Checking the Numeric Selector Setting on page 8-6
•
Checking the Globally Unique ID (GUID) on page 8-7
•
Checking the Fiber-Optic Cable Connections to the Switch Port on page 8-8
•
Checking the Switch Configuration, Firmware, and FPGA Images on page 8-9
•
Checking the VPROC File Version of Images for the Switch on page 8-9
•
Checking the Images Running on the Switch on page 8-9
