ServerNet Cluster 6780 Planning and Installation Guide—527301-005
A-1
A Part Numbers
This appendix lists the part numbers for hardware associated with a ServerNet cluster.
Service Classifications A-1
Switch Rack A-2
Switch A-2
Switch Components A-3
Uninterruptible Power Supply (UPS) A-3
Power Distribution Unit (PDU) A-4
Power Cords A-4
Power Cords for Connecting a 6780 Switch to a PDU or UPS A-4
Power Cords for Connecting a 6780 Switch Directly to an External Power
Source A-5
Fiber-Optic Cables A-7
ESD Protection Kit A-7
Modular ServerNet Expansion Board (MSEB) A-7
Service Classifications
The service classification for all hardware components in this appendix is CRU-3. For
more information about service classifications, refer to the CSSI Web.
The CSSI Web provides procedures, part numbers, troubleshooting tips, and tools for
servicing NonStop S-series systems.
A link to the CSSI Web can be found in the left navigation area of the NTL home page.
Authorized service providers can also order the CSSI Web and HSM CD:
•
Channel Partners and Authorized Service Providers: Order the CD from the SDRC
at https://scout.nonstop.compaq.com/SDRC/ce.htm.
•
HP employees: Subscribe at World on a Workbench (WOW). Subscribers
automatically receive CD updates. Access the WOW order form at
http://hiimpact.americas.cpqcorp.net/wow/order.asp.
Note. After G06.23, a snapshot of the CSSI Web is no longer included on the system console
installer CD.
