Part Numbers
ServerNet Cluster 6780 Planning and Installation Guide—527301-005
A-2
Switch Rack
Switch Rack
Switch
Part Number Description
527136 HP 10642 Rack
Part Number Description
524392 6780 HP ServerNet Switch, including:
•
Rack mount kit
•
Cable management assembly
•
6780 HP ServerNet Switch bezel
524393 6780 HP ServerNet Switch
524939 6780 HP ServerNet Switch bezel
526272 Rack mount kit, including:
•
Rails: left front, left rear right front, and right rear
•
10 Torx screws, M6
•
4 black nylon ties
526272 Cable management assembly, including:
•
Cable management assembly
•
Cable labels for fiber-optic cables
•
4 black nylon ties
