Using the Long-Distance Option
ServerNet Cluster 6780 Planning and Installation Guide—527301-005
G-4
Software Requirements for Two-Zone Long-Distance
Topologies
Software Requirements for Two-Zone Long-
Distance Topologies
On all NonStop S-series servers in a cluster that uses the long-distance option in a
two-zone 6780 ServerNet Cluster topology, you must install:
•
The G06.22 or a later RVU.
•
The T2790AAC configuration image for the 6780 switch or a superseding SPR.
T2790AAC is available only as a restricted SPR.
Table G-1 lists the minimum G-series software that supports the long-distance option in
two-zone topologies. Except for the T2790AAC switch configuration image, all of these
software products are part of the G06.22 RVU. Additional requirements apply if the
cluster contains HP NonStop NS-Series servers in addition to HP NonStop S-Series
Servers. For more details, please refer to the ServerNet Cluster Supplement for
NonStop NS-Series Servers.
Table G-1. Software That Supports the Long-Distance Option in Two-Zone
Topologies
Product Product Version Update (PVU)
NonStop Kernel T9050APF
SANMAN T0502AAM
SNETMON/MSGMON T0294AAM
6780 switch firmware T2789AAC
6780 switch FPGA T2819AAB
6780 switch configuration T2790AAC (restricted SPR)
Note. Installing these components separately on an RVU earlier than G06.22 is not
recommended. All nodes of a cluster that uses the long-distance option must be running
G06.22 or later.
