START PATH Command
The output from the above START PATH command shows that all FOX direct logical
paths from processor 12 on \GATE3 to processor 0 on \GATE7 were successfully
started.
The following command starts all the FOX direct logical paths from processor 1 in the
local cluster to all the processors in \GATE9:
SCF> START PATH $ZZFOX.1, TO \GATE9.*
The output from the above START PATH command shows that all FOX direct logical
paths from processor 1 on \GATE3 to all processor on \GATE9 were successfully
started.
SCF> START PATH $ZZFOX.12, TO \GATE7.0
FOX Detailed Status PATH \GATE3.$ZZFOX.12, TO \GATE7.0
At 11 May 2001, 15:40:05.327
Local Cluster
-------------
Cluster Number... 3 XLBU Logical State.... STARTED
System Name...... \GATE3 YLBU Logical State.... STARTED
System Number.... 60 TOS Version........... Q06
Remote Cluster(s)
-----------------
Cluster System System TOS CPUs Path CPU
Number Name Number Version UP Down Stuck
------- ------ ------ ------- ---- ---- -----
5 \GATE5 54 Q06 16 0 0
Processor-to-Processor Connectivity Matrix from \GATE3.12 to \GATE7.0
TO 0
X Y
FROM L R L R
12 . . . .
SCF> START PATH $ZZFOX.1, TO \GATE9.*
FOX Detailed Status PATH \GATE3.$ZZFOX.1, TO \GATE9.*
At 11 May 2001, 15:40:05.327
Local Cluster
-------------
Cluster Number... 3 XLBU Logical State.... STARTED
System Name...... \GATE3 YLBU Logical State.... STARTED
System Number.... 60 TOS Version........... Q06
Remote Cluster(s)
-----------------
Cluster System System TOS CPUs Path CPU
Number Name Number Version UP Down Stuck
------- ------ ------ ------- ---- ---- -----
9 \GATE9 53 Q06 16 0 0
Processor-to-Processor Connectivity Matrix from \GATE3.1 to \GATE9.*
TO 0 1 2 3 4 5 6 7
X Y X Y X Y X Y X Y X Y X Y X Y
FROM L R L R L R L R L R L R L R L R L R L R L R L R L R L R L R L R
1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
TO 8 9 10 11 12 13 14 15
X Y X Y X Y X Y X Y X Y X Y X Y
FROM L R L R L R L R L R L R L R L R L R L R L R L R L R L R L R L R
1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
