STATUS LBU Command
Example
The following example is similar to the display returned by the STATUS command for
an LBU object with the DETAIL option:
The following descriptions explain the fields returned by the STATUS DETAIL
command for the LBU object:
Summary State
identifies the summary state of the LBU object. The valid states are STARTED,
STOPPED, STARTING, ABORTING, DIAGNOSING, and UNKNOWN. Refer to
SCF and LBU Object States on page 4-3 for additional information.
Physical State
identifies the current physical state of the ServerNet/FX adapter. Possible states
are UNLOADED, LOADED, OPERATIONAL, NO RESPONSE and ???. Refer to
ServerNet/FX Adapter Physical States on page 4-5 for additional information.
Controller Type
identifies the type of controller. FX2SA identifies the controller as a ServerNet/FX 2
adapter. FXSA identifies the controller as a ServerNet/FX adapter.
Logical State
identifies the current logical state of the LBU object ($ZZFOX.#X or $ZZFOX.#Y).
Possible states are UNDEFINED, UNKNOWN, ABSENT, STOPPED, and
STARTED. Refer to SCF and LBU Object States on page 4-3 for additional
information.
SCF> STATUS LBU $ZZFOX.#X,DETAIL
FOX Detailed Status LBU \GATE7.$ZZFOX.#X At 08 May 2001, 13:02:35.543
Summary State..... STARTED Logical State..... STARTED
Physical State.... LOADED System Number..... 215
Controller Type... FX2SA Cluster Number.... 14
Serial Links: Quality Phy-Neighbor Log-Neighbor Status
Left: 0.9995 2 2 Link OK
Right: 0.9995 5 5 Link OK
Bootcode ID: T0059G05^19MAR98^04MAR98
Firmware ID: T0060G05^25SEP98^25AUG98
Server Net Aging Interval: 224 microseconds
Server Net Packet Timeout: 30 microseconds
Barrier Packet Timeout: 60 microseconds
Time Since LBU Start: 0 Days, 19:05:13.169803
Last Used Download Program File: $SYSTEM.SYS76.M6742
Module: STANDARD
