STATUS PATH Command
by using the DETAIL option. The example shows the FOX connectivity status from the
local cluster (\GATE3) to \GATE5:
The following descriptions explain the fields returned by the STATUS command for the
PATH object:
Cluster Number
identifies the FOX cluster number.
System Name
identifies the system name of the cluster.
System Number
identifies the system number of the cluster.
X(Y)LBU Logical State
identifies the current logical state of the LBU object ($ZZFOX.#X and $ZZFOX.#Y)
in the local cluster. Possible states are UNDEFINED, UNKNOWN, ABSENT,
STOPPED,
and STARTED. Refer to LBU Object Logical States on page 4-4 for
additional information.
TOS Version
identifies the operating system version running on the cluster.
CPUs UP
identifies the number of processors in the remote cluster that are up.
remote-processor in the command has no effect on this number.
Path Down
identifies the number of downed FOX direct logical paths for the specified FOX
connection.
SCF> STATUS PATH $ZZFOX.*, TO \GATE5.*
FOX Status PATH \GATE3.$ZZFOX.*, TO \GATE5.*
At 11 May 2001, 15:32:45.556
Local Cluster
-------------
Cluster Number... 3 XLBU Logical State.... STARTED
System Name...... \GATE3 YLBU Logical State.... STARTED
System Number.... 56 TOS Version........... Q06
Remote Cluster(s)
-----------------
Cluster System System TOS CPUs Path CPU
Number Name Number Version UP Down Stuck
------- ------ ------ ------- ---- ---- -----
5 \GATE5 54 Q06 16 5 4
