Logical Layout of a FOX Ring
Logical Layout of a FOX Ring
A FOX network is physically connected as a ring; however, it is logically configured
with the Expand subsystem as a fully connected mesh (that is, each cluster is only one
logical hop from any other cluster in the FOX network). Figure 1-1 shows the physical
and logical layout of a FOX ring with four clusters.
Figure 1-1. FOX Ring Physical and Logical Layout
VST045.VSD
Cluster 1
Cluster 4
$X252
Cluster 2
Key
Configured path.
Cluster 3
$LINE2
$LINE3
$LINE4
$LINE1
$LINE2
$LINE3
$LINE1
$LINE4
$LINE3
$LINE4
$LINE1
$LINE2
X
Y
X
Y
X
Y
X
Y
$LINEn The Expand-over-FOX line-handler process that connects to cluster n.
