Configuring the ServerNet/FX Adapter Subsystem

ServerNet/FX Adapter Configuration and Management Manual—426872-002

2-7

ServerNet/FX 2 Adapter LBU Examples

The following is an example of creating an LBU for the ServerNet/FX 2 adapter

connected to the X-ring:

ADD LBU $ZZFOX.#X, LOCATION (1,1,53), &

PROGRAM $SYSTEM.SYSTEM.M6742, MODULE STANDARD, &

SAMPLEINT 1:00:00.000, CLUSTERNUM 4, POWERLEFT 0, &

POWERRIGHT 0, STARTSTATE STARTED

The following is an example of creating an LBU for the ServerNet/FX 2 adapter

connected to the Y-ring:

ADD LBU $ZZFOX.#Y, LOCATION (1,1,54), &

PROGRAM $SYSTEM.SYSTEM.M6742, MODULE STANDARD, &

SAMPLEINT 1:00:00.000, CLUSTERNUM 4, POWERLEFT 0, &

POWERRIGHT 0, STARTSTATE STARTED

ServerNet/FX Adapter LBU Examples

The following is an example of creating an LBU for the ServerNet/FX adapter

connected to the X-ring:

ADD LBU $ZZFOX.#X, LOCATION (1,1,53), &

PROGRAM $SYSTEM.SYSTEM.M6740, MODULE STANDARD, &

SAMPLEINT 1:00:00.000, CLUSTERNUM 4, POWERLEFT 0, &

POWERRIGHT 0, STARTSTATE STARTED

The following is an example of creating an LBU for the ServerNet/FX adapter

connected to the Y-ring:

ADD LBU $ZZFOX.#Y, LOCATION (1,1,54), &

PROGRAM $SYSTEM.SYSTEM.M6740, MODULE STANDARD, &

SAMPLEINT 1:00:00.000, CLUSTERNUM 4, POWERLEFT 0, &

POWERRIGHT 0, STARTSTATE STARTED

Adding a NonStop S-Series Server to a FOX

Ring Overview

After the FOX monitor process has been created and started, and the LBUs have been

configured, you are ready to add the NonStop S-series server to an existing FOX ring.

The following provides an overview of the tasks necessary to add a NonStop S-series

server to a FOX ring. The tasks are explained in detail in Adding a Cluster to a FOX

Ring on page 3-14:

1. Disconnect the corresponding LBUs at the new cluster’s cable neighbors.

2. Physically insert the new cluster in the FOX ring.

Caution. Never put a copy of M6742 in the $SYSTEM.SYSTEM subvolume.

Caution. Never put a copy of M6740 in the $SYSTEM.SYSTEM subvolume.
