Switching Primary and Backup Processors for the
FOX Monitor Process
Switching Primary and Backup Processors for the FOX Monitor
Process
Use the ServerNet/FX adapter subsystem SCF PRIMARY PROCESS command to
switch the primary configured processor for the FOX monitor process ($ZZFOX) to the
backup configured processor or to switch the backup configured processor to the
primary configured processor.
The following command switches the primary configured processor for $ZZFOX to the
backup configured processor 3:
SCF> PRIMARY PROCESS $ZZFOX, 3
Deleting the FOX Monitor Process ($ZZFOX) using the Kernel
Subsystem
Use the Kernel subsystem SCF DELETE PROCESS command to delete the FOX
monitor process ($ZZFOX). For example, the following SCF DELETE PROCESS
command deletes the FOX monitor process named ZZFOX:
SCF> DELETE PROCESS $ZZKRN.#ZZFOX
Refer to the SCF Reference Manual for the Kernel Subsystem for more information
about the SCF DELETE PROCESS command.
Adding a Cluster to a FOX Ring
This subsection explains how to add a NonStop S-series server to an existing FOX
ring.
Task 1: Disconnect the corresponding LBUs at the cable
neighbors
Before you insert a NonStop S-series server into an existing FOX ring, you must
logically disconnect the FOX links at the left and right cable neighbors (the servers
between which you plan to insert the NonStop S-series server).
To disconnect the LBUs, issue the following SCF commands:
At the left cable neighbor:
Note. The FOX monitor process ($ZZFOX) can only be deleted after a system load or
processor reload. Refer to Creating the FOX Monitor Process on page 2-3 for information.
Note. Adding a NonStop K-series system running the D-series NonStop Kernel operating
system to a FOX ring is explained in the Expand Network Management Guide for D-series
systems.
