ALTER Command
STARTSTATE
The STARTSTATE attribute specifies the start mode of the ServerNet/FX
adapter. A value of STARTED specifies that the ServerNet/FX adapter will be
started automatically when the system is loaded. A value of STOPPED
specifies that the ServerNet/FX adapter will not be started automatically when
the system is loaded, and must be manually started using the ServerNet/FX
adapter subsystem SCF START LBU command.
POWERLEFT
The POWERLEFT attribute specifies the power level (powerlevel) for the
link to the left cluster. The Left Out fiber connector on the ServerNet/FX
adapter provides the link from the adapter to the left cluster. A value of 0
specifies a low power level and is used for distances up to 2 Km. A value of 1
specifies a high power level and is used for distances from 2 Km to 4 Km.
POWERRIGHT
The POWERRIGHT attribute specifies the power level (powerlevel) for the
link to the right cluster. The Right Out fiber connector on the ServerNet/FX
adapter provides the link from the adapter to the right cluster. A value of 0
specifies a low power level and is used for distances up to 2 Km. A value of 1
specifies a high power level and is used for distances from 2 Km to 4 Km.
Default STARTED
Units Not applicable
Range STARTED/STOPPED
Default 0
Units Not applicable
Range 0 to 1
WARNING. Damage can result if the powerlevel is set to 1 for distances up to 2 Km.
Default 0
Units Not applicable
Range 0 to 1
WARNING. Damage can result if the powerlevel is set to 1 for distances up to 2 Km.
