Using the SPAM Performance Data Charts and
Reports
Tandem Performance Data Collector (TPDC) Manual—526357-001
5-65
Global Indicators (COVER)
Global Indicators (COVER)
This 74-column report is a cover page for the set of charts and reports. It shows global
information, which includes:
•
The date and time of the measurement taken
•
The system measured
•
The numbers and types of CPUs
•
The total, average, low, and high values for key performance metrics
This report uses the GLOBINFO entity.
Parameters used are:
•
LID—specifies the Measure Load ID
•
SECTION—specifies the report section number
MEASURE Load ID: G1530MC1
================ ========
System: \CSO (Release D20)
------- --------
Date: 08/02/93 (MON)
From: 15:30:16
To: 16:30:41 (Window = 3624.90 seconds)
CPUs: 4 (TXP 0, VLX 4, CLX 0, CYC 0)
TOTAL AVERAGE LOWEST HIGHEST
------- ------- ------- -------
Real Memory Pages 49152 12288 12288 12288
Estimated Free Pages 26356 6589 5627 8175
Static Processes 216 54 40 68
Transient Processes 0 0 0 0
Dispatches/Second 207.4 51.8 25.3 65.6
Total CPU Busy 38.3% 9.6% 6.0% 14.1%
Process Busy 32.4% 8.1% 5.3% 12.6%
Interrupt Busy 5.8% 1.5% .7% 1.8%
CPU Queue Length - .1 .1 .2
Memory Queue Length - .0 .0 .0
Swaps/Second .3 .1 .0 .1
Process Overhead .1% .0% .0% .0%
Send Busy .3% .1% .0% .1%
TMF Transactions/Second - - - -
TMF Transaction Time (msec) - - - -
Logical Disc I-O's/Second 23.8 - - -
Logical Disc I-O Time (msec) - 7.2 - -
Records Used/Accessed Ratio - - - -
Disc Cache Hits/Second 36.8 12.3 3.9 21.1
Physical Disc I-O's/Second 5.4 1.8 .5 3.6
