TR3271 Management Programming Manual

COMMANDS AND RESPONSES
STATISTICS Command
ZSPI-TKN-CONTEXT token-type ZSPI-TYP-BYTESTRING.
ZSPI-TKN-RESPONSE-TYPE token-type ZSPI-TYP-ENUM.
ZSPI-TKN-ALLOW-TYPE token-type ZSPI-TYP-ENUM.
ZSPI-TKN-COMMENT token-type ZSPI-TYP-STRING.
Tokens in Response Buffer
ZSPI-TKN-SSID token-type ZSPI-TYP-SSID. !{}
ZSPI-TKN-SERVER-VERSION token-type ZSPI-TYP-INT. !{}
ZSPI-TKN-DATALIST token-type ZSPI-TYP-LIST. !...
ZTR3-MAP-STATS-LINE !OBJ-LINE
!SUB
def ZTR3-DDL-STATS-LINE. !All fields are present.
02 ZRESET-TIME type ZSPI-DDL-TIMESTAMP.
02 ZSAMPLE-TIME type ZSPI-DDL-TIMESTAMP.
02 ZTR3-LINE-CLB.
04 ZTOTAL-FRAME type ZSPI-DDL-INT.
04 ZBCC-ERR type ZSPI-DDL-INT.
04 ZFRAME-ERR type ZSPI-DDL-INT.
04 ZNO-BUF type ZSPI-DDL-INT.
02 ZTR3-LINE-L2.
04 ZTOTAL-MSG type ZSPI-DDL-INT.
04 ZMSG-SENT type ZSPI-DDL-INT.
04 ZMSG-RECVED type ZSPI-DDL-INT.
04 ZSHORT-BUF type ZSPI-DDL-INT.
04 ZL2-ERR type ZSPI-DDL-INT.
04 ZNAK type ZSPI-DDL-INT.
04 ZBCC-ERR type ZSPI-DDL-INT.
04 ZFRMT-ERR type ZSPI-DDL-INT.
04 ZRETRY type ZSPI-DDL-INT.
04 ZMSG-L256-SENT type ZSPI-DDL-INT.
04 ZMSG-L256-RECVED type ZSPI-DDL-INT.
04 ZMSG-L1024-SENT type ZSPI-DDL-INT.
04 ZMSG-L1024-RECVED type ZSPI-DDL-INT.
04 ZMSG-G1024-SENT type ZSPI-DDL-INT.
04 ZMSG-G1024-RECVED type ZSPI-DDL-INT.
end.
ZTR3-MAP-STATS-SU !OBJ-SU
!SUB
def ZTR3-DDL-STATS-SU. !All fields are present.
02 ZRESET-TIME type ZSPI-DDL-TIMESTAMP.
02 ZSAMPLE-TIME type ZSPI-DDL-TIMESTAMP.
02 ZERR type ZSPI-DDL-INT.
02 ZMSG-SENT type ZSPI-DDL-INT.
02 ZMSG-RECVED type ZSPI-DDL-INT.
end.
>
6-90
