TR3271 Management Programming Manual

TR3271 EVENT MANAGEMENT
147: ZTR3-EVT-CSS-PROBE-ERR
For details on any of the EMS tokens, refer to the Event
Management Service (EMS) Manual .
Volatile Tokens
ZEMS-TKN-CU is a standard EMS token that contains the controller
and unit number. This token is present in the event buffer only
if the controller uses subchannel-type I/O addressing.
Event-Message Text
In the text message, ldev corresponds to the value of ZEMS-
TKN-LDEV, n,n,%nn,%nnn corresponds to the value of ZEMS-MAP-
EXIOADDR, ldevname corresponds to the value of ZEMS-TKN-LDEVNAME,
path corresponds to the value of ZCOM-TKN-NEW-PATH, and probe-err
corresponds to the value of ZTR3-TKN-PROBE-ERR,
Probable Cause
The TR3271 subsystem received a status probe response from the
CLIP indicating that it is in the boot state instead of the run
state. The TR3271 subsystem attempts to download the CLIP again.
If this cannot be done on the primary path, TR3271 attempts a
download on another path. The value path indicates the primary
path. The possible values are ZCOM-VAL-PATH-A and ZCOM-VAL-PATH-
B.
The value probe-err in the text message contains the CLIP status
byte. The possible values are as follows:
Value Meaning
-1 no response--timed out
on probe status
-2 unexpected probe status
1 CLB type--normal frame
2 CLB type--first frame
3 CLB type--continue
4 CLB type--last frame
5 CLB type--abort
6 CLB type--error
7-42
