157: ZTR3-EVT-CSS-FRAME-ERR
157: ZTR3-EVT-CSS-FRAME-ERR
An invalid frame was received. The IOP may detect this error
when the CLIP resets itself. The CLIP may reset itself as a
result of a problem it detects. This event is critical, and the
event message is reported to the EMS collector ($0). This event
message is equivalent to console message 157.
Unconditional Tokens
ZSPI-TKN-SSID token-type ZSPI-TYP-SSID.
ZEMS-TKN-EVENTNUMBER token-type ZSPI-TYP-ENUM.
ZEMS-TKN-SUBJECT-MARK token-type ZSPI-TYP-MARK.
ZEMS-TKN-LDEVNAME token-type ZSPI-TYP-FNAME32.
ZEMS-TKN-LDEV token-type ZSPI-TYP-UINT.
ZEMS-TKN-EMPHASIS token-type ZSPI-TYP-BOOLEAN.
ZEMS-TKN-CONSOLE-PRINT token-type ZSPI-TYP-BOOLEAN.
ZEMS-TKN-CPU token-type ZSPI-TYP-UINT.
ZEMS-TKN-CRTPID token-type ZSPI-TYP-CRTPID.
ZEMS-TKN-GENTIME token-type ZSPI-TYP-TIMESTAMP.
ZEMS-TKN-LOGTIME token-type ZSPI-TYP-TIMESTAMP.
ZEMS-TKN-PIN token-type ZSPI-TYP-UINT.
ZEMS-TKN-SYSTEM token-type ZSPI-TYP-UINT.
ZEMS-TKN-USERID token-type ZSPI-TYP-BYTE-PAIR.
ZCOM-TKN-NEW-PATH token-type ZSPI-TYP-ENUM.
ZTR3-TKN-FRAME-ERR token-type ZSPI-TYP-UINT.
ZTR3-TKN-ADDR-CTL token-type ZSPI-TYP-UINT.
ZTR3-TKN-TYPE-SEQ token-type-ZSPI-TYP-UINT.
Volatile Tokens
ZEMS-TKN-CU token-type ZSPI-TYP-UINT.
Tandem Internal Tokens
ZEMS-MAP-EXIOADDR
Event-Message Text
Display and Console-Compatible Format:
LDEV ldev I/O ADDR ( n,n,%nn,%nnn ) ldevname
CSS FRAME ERROR CIU path ERROR = % frame-err
A,C = % param1 T,S = % param2
