TR3271 EVENT MANAGEMENT
165: ZTR3-EVT-CSS-SUBDEV-ERR
165: ZTR3-EVT-CSS-SUBDEV-ERR
The Communications Line Interface Processor (CLIP) of the 6100
Communications Subsystem (CSS) responded to the TR3271 I/O
process with an invalid subdevice state. This event is critical,
and the event message is reported to the EMS collector ($0).
This event message is equivalent to console message 165.
Unconditional Tokens
ZSPI-TKN-SSID token-type ZSPI-TYP-SSID.
ZEMS-TKN-EVENTNUMBER token-type ZSPI-TYP-ENUM.
ZEMS-TKN-SUBJECT-MARK token-type ZSPI-TYP-MARK.
ZEMS-TKN-LDEVNAME token-type ZSPI-TYP-FNAME32.
ZEMS-TKN-LDEV token-type ZSPI-TYP-UINT.
ZEMS-TKN-EMPHASIS token-type ZSPI-TYP-BOOLEAN.
ZEMS-TKN-CONSOLE-PRINT token-type ZSPI-TYP-BOOLEAN.
ZEMS-TKN-CPU token-type ZSPI-TYP-UINT.
ZEMS-TKN-CRTPID token-type ZSPI-TYP-CRTPID.
ZEMS-TKN-GENTIME token-type ZSPI-TYP-TIMESTAMP.
ZEMS-TKN-LOGTIME token-type ZSPI-TYP-TIMESTAMP.
ZEMS-TKN-PIN token-type ZSPI-TYP-UINT.
ZEMS-TKN-SYSTEM token-type ZSPI-TYP-UINT.
ZEMS-TKN-USERID token-type ZSPI-TYP-BYTE-PAIR.
ZCOM-TKN-NEW-PATH token-type ZSPI-TYP-ENUM.
ZTR3-TKN-CLIP-SU token-type ZSPI-TYP-UINT.
ZTR3-TKN-CLIP-STATUS token-type ZSPI-TYP-UINT.
ZTR3-TKN-CLIP-FUNC token-type ZSPI-TYP-UINT.
Volatile Tokens
ZEMS-TKN-CU token-type ZSPI-TYP-UINT.
Tandem Internal Tokens
ZEMS-MAP-EXIOADDR
ZCDG-TKN-SUBDEV-NUM token-type ZSPI-TYP-UINT.
Event-Message Text
Display and Console-Compatible Format:
LDEV ldev I/O ADDR ( n,n,%nn,%nnn ) ldevname
CSS SUBDEVICE ERROR, CIU path
SUBDEV # param1 F,M = % param2 STATUS % param3
>
