XYGATE Merged Audit
®
Reference Manual
Quick Reference for Common Tasks
XYPRO Technology Corporation xv Proprietary and Confidential
Quick Reference for Common Tasks
No. Type Task Steps
24. SLSENDER
Re-send events to
the SIEM
Select Database Menu option 13, page 104.
25. SLSENDER
Remove obsolete
events from the
SYSLOG Queue
Select Database Menu option 14, page 104.
26. SLSENDER
Change number of
copies running
Select Movers Menu option 21, page 101.
27. Database
FUP RELOAD the
data tables
Perform FUP Reloads, page 152.
28. Database
UPDATE
STATISTICS
Note: The pathway must be stopped before Updating
Statistics:
1) Stop Pathway Menu option 3, page 100.
2) Select Database Menu option 1, page 104.
29. Database
View or change TMF
auditing parameters
Selecting Database Menu option 12 on page 104 allows
you to view or change TMF auditing parameters.
30. Database Partitioning
Refer to section 8.4, “Partitioning the XMA Database” on
page 154.
31. Database Resizing
Refer to section 8.3, “Resizing the Data Tables” on
page 153.
32. Database
Upgrading XMA
prior to ver. 1.95.
Refer to section 1.5, “Upgrade Considerations” on
page 21.
33. Maintenance
Install new license
on Pathway node
Run XMA_INSTALL_LICENSE macro (page 218) on
each node where you have a XYGATE subvolume.
34. Maintenance
Install new license
on remote nodes
Once you have upgraded the license in the XYGATE
subvolume, run XMA_NETWORK_LICENSE_INSTALL
macro (page 219).
35. Maintenance
Upgrade the XMA
software
Refer to section 1.4.1, “Running the AutoInstall Upgrade”
on page 16.
36. Maintenance
SQL Compile all the
XMA objects
Run XMA_SQLCOMPALL macro (page 221), ensuring
you have attached the segment first.
37. Maintenance
SQL Compile a
single XMA objects
1) Go to your XMA subvolume:
volume $<vol>.xygatema
2) Load the XMA Macro:
run $<vol>.xygatema.xma install
3) Load the defines for the database tables:
XMA_load_defines
4) Run SQLCOMP for the desired object:
Run $system.system.sqlcomp/in
<program>,out $s.#out/catalog xma_cat
