XYPRO Technology Corporation 157 Proprietary and Confidential
Chapter 9. Troubleshooting
This chapter describes the XMAHELP functions and guides you through the steps to
troubleshoot the following:
• NonStop (XMA) side of the communication with an audit logging appliance system.
• Audit Log Warehouse Data Parsing.
9.1 XMAHELP/XMA_HELP
Displays information regarding the available XMA Macros.
SYNTAX
XMAHELP
9.1.1 XYMOVE Functions
The program XYMOVE extracts information from the XYGATE product audit trails. The
program XYMOVE can also be run with two options:
• CHECKFILTERS performs a syntax check on the FILTERS file.
• XYGATEVER generates a list of supported XYGATE product versions.
9.1.2 CHECKFILTERS XYMOVE Option
This function performs a syntax check of your FILTERS file.
Syntax:
RUN $<vol>.<subvol>.XYMOVE CHECKFILTERS <FILTERs file name>
Where $<vol>. <subvol> is the location of your XMA installation.
You can specify a filename so you have to create a temporary version of your
FILTERS file with an alternative name to review prior to moving it into production.
Note: All Filter Definitions including those with a STATUS of INACTIVE will be
checked for syntax error.
Example: Sample output from CHECKFILTERS:
>RUN XYMOVE CHECKFILTERS tempfilt
XMA 1.71 (c) 1999-2010 XYPRO XYPRO \PROD1 20011231
FILTERS CHECKSUM 1141462806
No syntax errors found
For a more information about Filters syntax checking, refer to Appendix E13:
“XMA_FILTERS_CHECK” on page 216.
