XYGATE Merged Audit
®
Reference Manual
Chapter 9. Troubleshooting
XYPRO Technology Corporation 158 Proprietary and Confidential
9.1.3 XYGATEVER XYMOVE Option
Running XYMOVE with the XYGATEVER option provides a list of all supported
XYGATE products and their associated minimum version required for XMA. It only lists
a version again if the audit file layout has changed
Syntax:
RUN $<vol>.<subvol>.XYMOVE XYGATEVER
Where:
<$vol>. <subvol> is the location of your XMA installation.
Sample output from XYGATEVER
23> run $system.xygatema.xymove xygatever
23..
XMA 1.71 (c) 1999-2010 XYPRO XYPRO Technology \PROD1 20011231
XYGATEAC 4.15 uWWEnEBUyVgpwSoOkIETVIw48cA=
XYGATEAC 5.10 8fYqaYA6FZb846KezEJQXmwtrmE=
…
XYGATEOS 2.10 4dI4FQIz9CJTKXySrJkvo6TWNhU=
XYGATEEF 1.60 LGpH9xeQ/6tWRqvg+LOt5pUpcrU=
XYGATEKM 1.00 6ieUvpOgBD5viIb+azMRygIxuZo=
The information after XYGATE product version number is a hash of the LOGDDL file
for the product. The XYMOVE program uses this hash to determine which version of a
XYGATE product is installed so that the correct audit file layout for that product is used
for extracting audit data.
9.2 Communication with an Audit Logging Appliance System
Use this section to help you troubleshoot the communication side of the NonStop
(XMA) with an audit logging appliance system.
9.2.1 Verify that IPALERT Filter(s) Status Is Active
Attach the XMA TACL segment and run the XMA_EDIT_FILTERS macro to view the
status of all the IPALERT Filters. Example 1 shows that the two SYSLOG Filters are
active.
Example 1:
$DATA04 XYGATEMA 12> RUN $DATA04.XYGATEMA.XMA INSTALL
$DATA04.XYGATEMA 1> xma_edit_filters
This file edits the current XYGATE_MERGED_AUDIT FILTERS FILE
It will create a file named $DATA04.XYGATEMA.NEWFILT from
the current $DATA04.XYGATEMA.FILTERS file.
These are your old $DATA04.XYGATEMA.FILTERS files:
$DATA04.XYGATEMA
CODE EOF LAST MODIFIED OWNER RWEP PExt SExt
OLDFLT00 101 50624 24OCT2008 16:07 222,77 OOOO 14 28
OLDFLT01 101 53348 06NOV2008 16:00 222,77 OOOO 14 28
OLDFLT02 101 53380 05DEC2008 15:30 222,77 OOOO 14 28
