XYGATE Merged Audit
®
Reference Manual
Chapter 9. Troubleshooting
XYPRO Technology Corporation 159 Proprietary and Confidential
FILES DUPLICATED: 1
TEXT EDITOR - T9601H01 - (01MAY05)
CURRENT FILE IS $DATA04.XYGATEMA.NEWFILT
*lb/status/
29 STATUS ACTIVE ! $IGNORE-XAC-00002-RECORDS
51 STATUS ACTIVE ! $IGNORE-XCM-ALIVE-MSG
70 FILTERDEFBEGIN $IGNORE-XPC-STATUS-CMD
71 STATUS ACTIVE ! $IGNORE-XPC-STATUS-CMD
92 STATUS INACTIVE ! $IGNORE-MEASFH
112 STATUS ACTIVE ! $IGNORE-UNWANTED-SFG-CODES
162 STATUS ACTIVE ! $IGNORE-UNWANTED-USER-DB-READS
191 STATUS ACTIVE ! $IGNORE-XOS-NORECORD-AND-WHATIF
. . .
1518 STATUS ACTIVE ! $SYSLOG_ALL_EMS_EVENTS
1607 STATUS ACTIVE ! $SYSLOG_ALL_NON_EMS_EVENTS
9.2.2 Verify that Pathway and the MOVERs Are Running
Use PATHCOM to check the status of the XMA pathway and servers:
1> Pathcom <pathway name, $XMA, is the default>
Status server *
1 = MOVER is running; 0 = MOVER is not running
Example 2 shows that the $XMA pathway and all the MOVERs are running.
Example 2:
$DATA04.XYGATEMA 4> pathcom $xma
$X0GS: PATHCOM - T8344H01 - (01AUG08)
(C)1980 Tandem (C)2005 Hewlett Packard Development Company, L.P.
=status server *
SERVER #RUNNING ERROR INFO
EMS-X-01 1
HKEEPER 1
MQREADER 1
SFG-S7-01 1
SFG-X-01 1
XAC-S7-01 1
XAC-X-01 1
XCM-S7-01 1
XCM-X-01 1
XHE-S7-01 1
XHE-X-01 1
XOS-S7-01 1
XOS-X-01 1
XPC-X-01 1
XPQ-S7-01 1
XPQ-X-01 1
XSM-X-01 1
XSP-X-01 1
XTR-X-01 1
XUA-X-01 1
=
You can also use the Pathway Management Menu, option 4: Quick Server Status
(page 100) to check if the pathway and the MOVERs are running.
