XYGATE Merged Audit
®
Reference Manual
Appendix E: XMA Host Macros
XYPRO Technology Corporation 215 Proprietary and Confidential
E12: XMA_EDIT_FILTERS
The XMA_EDIT_FILTERS macro allows the user to edit a duplicate copy of the
FILTERS file and then load it into production.
Syntax
XMA_EDIT_FILTERS
Example XMA_EDIT_FILTERS
$SECURE XYGATEMA 16> xma_edit_FILTERs
This file edits the current XYGATE-ACCESS-CONTROL access control
list. It will create a file named $SYSTEM.XYGATEMA.NEWFILT from
the current $SYSTEM.XYGATEMA.FILTERS file.
These are your old $SYSTEM.XYGATEMA.FILTERS files:
$SYSTEM.XYGATEMA
CODE EOF LAST MODIFIED OWNER RWEP PExt SExt
OLDFLT0 101 6424 12JUL2001 11:03 222,210 NUUU 8 32
FILES DUPLICATED: 1
TEXT EDITOR - T9601D20 - (01JUN93)
CURRENT FILE IS $SYSTEM.XYGATEMA.NEWFILT
[Make the desired changes to NEWFILT]
exit
Checking for SYNTAX errors in the NEWFILT
XMA 1.71 (c) 1999-2010 XYPRO XYPRO Technology \PROD1 20011231
FILTERS CHECKSUM 1243425871
No syntax errors found
Do you want to install the new Filters?y
FILES DUPLICATED: 1
Last generation is $SYSTEM.XYGATEMA.oldflt1
FILTERS file is updated to NEWFILT contents
$SECURE XYGATEMA 17>
In this Example a copy of the FILTERS file called NEWFILT was created. The editor is
then invoked and the desired changes were made to the file NEWFILT.
After the editor sessions terminates, a syntax check is performed on the updated
NEWFILT file. Because no errors were detected, a prompt was displayed asking if the
NEWFILT file should be used to replace the production FILTERS file.
And because the response to the prompt was Yes, the FILTERS file was renamed to
OLDFLT1 and the NEWFILT file was renamed to FILTERS.
