XYGATE Merged Audit
®
Reference Manual
Appendix E: XMA Host Macros
XYPRO Technology Corporation 218 Proprietary and Confidential
E14: XMA_INSTALL_LICENSE
The XMA_INSTALL_LICENSE macro allows the XMA security administrator to check
on a newly received license file and optionally load it to P28F001 on the volume and
subvolume where XMA is installed. If you choose to load the new license, XMA
renames the current license file (at the red arrow below) out of the way and moves the
new license into place.
Once you have installed the new license on the Master node, use the macro
XMA_NETWORK_LICENSE_INSTALL to update the licenses on all your Child nodes.
Syntax:
xma_install_license <new license name>
The following Example shows the examination of a license file called IP28f001 and the
prompt for installing it.
Example
$SECURE XYGATEMA 9> xma_install_license $WORK.p28dsdst.ip28f001
Xypro license check XYPRO Technology \PROD1 20011231
XYPRO Technology P28-0026 20011231 \PROD2(252) \PROD3(254) \PROD1(253)
--BEGIN XYPRO SIGNATURE
PUBLIC-KEY:
LICENSE-CREATE: 20010614-092901
CUSTOMER-NAME: XYPRO Technology
CUSTOMER-NUMBER: 0026
PRODUCT: XYGATE-MA 20011231
NODE: \PROD2 0252
NODE: \PROD3 0254
NODE: \PROD1 0253
License good
Do you want to install this license file <YES>?y
FILES DUPLICATED: 1
New license installed, old license in $SYSTEM.XYGATEMA.XMA42444
Notice that the old license file is renamed to XMA42444 (at the red arrow above) when
the new license is installed as P28F001. The old license file (now renamed) is
available for fallback purposes should there be a problem in the new license. Simply
rename the two files to place the old license back in place.
Note: If the XMA license file is expired or bad, then none of the XYGATEMA features
will be available. If the license is expired or invalid, XYGATEMA will send a
message to EMS. If the license expires in less than 30 days, then XMA will audit
the warning message that the license is going to expire in less than 30 days.
