XYGATE Merged Audit

®

Reference Manual

Appendix E: XMA Host Macros

XYPRO Technology Corporation 226 Proprietary and Confidential

E27: XMA_VOLUME

The XMA_VOLUME macro takes you to your XMA installation subvolume.

Syntax

XMA_VOLUME
