XYGATE Merged Audit
®
Reference Manual
Chapter 1. Installing XMA
XYPRO Technology Corporation 3 Proprietary and Confidential
Table 2: Defaults for User-Defined Values
Config File Configuration Settings Default or User-Defined Value
$VOL references for locating all files Current $VOL | <user-value>
A unique subvolume name for the SQL
tables
XMADAT | <user-value>
A unique SUBVOL for the installed
software for XMA
XYGATEMA | <user-value>
A unique SUBVOL for the installed
software for XTR
XYGATETR | <user-value>
A unique <4-character> name for the
Pathway process; example $ZXMA
$XMA# | <user-value>
A PORT number between 1025-32000
for the TCP/IP LISTNER process
1120 | <user-value>
Additional users or aliases that need
access to run XMA (optional)
Owner of script plus SUPER.SUPER
plus additional <user-values>
MACONF XMA PATHMON_NAME $???? | <user-value>
Table 3 defines default configuration values and file locations that will be generated
automatically by the AutoInstall script.
Table 3: AutoInstall-Assigned Default Values or Locations
Config File Configuration Settings Default Values Assigned by
AutoInstall Script or Locations
A staging subvolume for installation only.
May be removed after installation has
been completed.
P46DSDST
A unique subvolume name for the SQL
catalog
XMACAT
A unique SUBVOL for Pathway
configuration files
XMAPW
MACONF XMA MACRO_NAME XMA
MACONF XMA PERUSE_OBJECT (selected from
available PERUSE objects)
$SYSTEM.SYSTEM.PERUSE
MACONF XMA HOME_TERM (selected from
available standard hometerms)
$VHS
$ZHOME
$YMIOP.#CLCI
MACONF XMA COLLECTOR (selected from
available spooler collectors)
$S
MACONF XMA process priority 30
TRCONF XTR MACRO_NAME XTR
TRCONF XTR audit trail file location $VOL.XYGATETR.AUDIT
TRCONF XTR audit parameters;
AUDIT_ACCESS_PASS +
AUDIT_ACCESS_FAIL
ON
