XYGATE Merged Audit
®
Reference Manual
Appendix G: Data Mapping
XYPRO Technology Corporation 254 Proprietary and Confidential
G6: HLR Data Mapping
HLR Audit Detail Table
Column Type Record Contents
PARTITIONKEY
See General Note 1, pg 240.
numeric 4 MOVER Generated
RECORDGMT See General Note 2.
timestamp MOVER Generated (the GMT time
equivalent of AUDIT.RECORDLCT).
GMTSEQNO char 2 MOVER Generated
RECORDLCT timestamp Date-time (the Local time that the
audit event occurred (as recorded in
the HLR audit trail).
RECORDAUDITKEY timestamp MOVER Generated
RECORDSESSIONKEY timestamp MOVER Generated (unique
timestamp created when the first
session row is inserted into XMA
database).
SEQNO char 9 MOVER Generated (the sequence of
records within an HLR session; refer
to the SESSION.SESSIONID
column).
OUTCOME char 1 4 (unknown) or 3 (failure) if the result
text contains "Security Violation."
WARNINGMODE char 1
TESTMODE char 1
Blank or "F" See HLR Note 5.
SEVERITY char 1
ALERTED See General Note 4.
char 1 MOVER Generated
PRODUCTCODE char 10 "HLR"
SUBJECT_USERNUMBER_MAJOR char 8
SUBJECT_USERNUMBER_MINOR char 8
SUBJECTLOGIN varchar 40 DPA userid of the person performing
the action or logging on.
SUBJECTSYSTEM varchar 64 The node where the HLR audit trail
resides.
TARGET_USERNUMBER_MAJOR char 8
TARGET_USERNUMBER_MINOR char 8
TARGETLOGIN varchar 40
OBJECTTYPE - Type of Object varchar 32 Object type that is being manipulated
GSUB, USER, SIM or CGSUB.
OBJECTNAME - Name of Object varchar 200 The record being changed: USERID,
MKEY or KEY.
See HLR Note 1.
Continued . . .
