XYGATE Merged Audit
®
Reference Manual
Chapter 1. Installing XMA
XYPRO Technology Corporation 4 Proprietary and Confidential
Config File Configuration Settings Default Values Assigned by
AutoInstall Script or Locations
TRCONF XTR option USER_SWITCH ON
TRCONF XTR process priority 152
TRCONF XTR HOME_TERM (selected from
available standard hometerms)
$VHS
$ZHOME
$YMIOP.#CLCI
TRCONF XTR PERUSE_OBJECT (selected from
available PERUSE objects)
$SYSTEM.SYSTEM.PERUSE
TRCONF XTR COLLECTOR (selected from
available spooler collectors)
$S
TRCONF XTR working subvolume $VOL.XYGATETR
TRCONF XTR option MAX_TASK_COUNT 5
TRCONF XTR option REPORT_OWNER 0,0
TRCONF XTR option TR_MASTER_SUBVOL $VOL.XYGATETR
TRCONF XTR encryption options OFF
TRCONF XTR SSL options OFF
TRCONF XTR monitor/debug options OFF
TRACL XTR/XMA $OWNER Authorized users OWNER running the script +
SUPER.SUPER
TRACL XTR option TR_INSTALLATION IP + Port number
PWCOLD Pathway startup macro $VOL.XMAPW
PWSTOP Pathway shutdown macro $VOL.XMAPW
PWCOOL Pathway cool start macro $VOL.XMAPW
PWCONFIG
Pathway general configuration settings $VOL.XMAPW
Pathway configuration setting for
PATHWAY OWNER
PAID of script
Pathway configuration setting for
PATHWAY SECURITY
“U”
Pathway configuration setting for CPUs Not set; default to Pathway
MACONF PATHWAY process for HOMETERM as defined in MACONF
PWSTATE
Pathway server configuration settings $VOL.XMAPW
Pathway configuration setting for OWNER PAID of script
Pathway configuration setting for
SECURITY
“U”
Pathway configuration setting for TMF ON
Pathway configuration setting for PRI 100
Pathway configuration setting for
HOMETERM
as defined in MACONF
Pathway configuration setting for CPUs Not set; default to Pathway
