XYGATE Merged Audit
®
Reference Manual
Appendix G: Data Mapping
XYPRO Technology Corporation 256 Proprietary and Confidential
HLR Note 1 – DPA Entity-Type
The entity being manipulated. The most common values are: USER, GSUB, SIM, or
CGSUB
Processing Based on Entity Type:
Entity-Type = User
(Indicates a logon, logoff, or a change to DPA userid)
DPA Identifier Value Notes XMA Column
EntityType= USER Entity Type being
manipulated
AUDIT.OBJECTTYPE
Name= USERID Type of obj being
manipulated
AUDIT.MESSAGEID
<DPA user
name>
If the operation is
LOGON or LOGOFF
AUDIT.MESSAGEID
User= <DPA user
name>
Indicates the DPA userid
that is making the
change.
If the operation is
LOGON, this column is
blank.
AUDIT.SUBJECTLOGIN
Command= <operation> Operation performed. AUDIT.OPERATION
If the operation
is LOGON
<DPA username> is the
person logging on. Userid
is placed in 2 columns
AUDIT.SUBJECTLOGIN
AUDIT.OBJECTNAME
Value= <DPA user
name>
The DPA userid being
manipulated
AUDIT.OBJECTNAME
Property String= From one to
many params
being set
Comma separated list of
parameters being set
AUDIT.RESULT
"PARAM" AUDIT.RULENAME
Value= <DPA user
name>
The DPA userid being
manipulated
AUDIT.OBJECTNAME
