XYGATE Merged Audit
®
Reference Manual
Appendix G: Data Mapping
XYPRO Technology Corporation 257 Proprietary and Confidential
Entity-Type = GSUB, CGSUB, or SIM
(Indicates that a cell phone account is being manipulated)
DPA Identifier Value Notes XMA Column
EntityType= GSUB, SIM,
CGSUB
Entity Type being
manipulated
AUDIT.OBJECTTYPE
Name= KEY Type of object being
manipulated
AUDIT.MESSAGEID
User= <DPA user
name>
Indicates the DPA userid
that is making the change.
AUDIT.SUBJECTLOGIN
Command= DPA Command= Operation performed AUDIT.OPERATION
Value= <Phone number> The phone account being
manipulated
AUDIT.OBJECTNAME
PropertyString= From one to
many params
being set
Comma-separated list of
parameters being set
AUDIT.RESULT
"PARAM" AUDIT.RULENAME
The following is placed in the AUDIT.OBJECTNAME column:
• If the EntityType = USERID, the value is the <DPA userid> being worked on or
logging on or off.
• If the TargetName = MKEY, the value is the MSISDN (sim card) number being
worked on.
• If the TargetName = KEY, the value is the IMSI (subscriber’s phone number) being
worked on.
