XYGATE Merged Audit
®
Reference Manual
Appendix G: Data Mapping
XYPRO Technology Corporation 258 Proprietary and Confidential
HLR Note 2 - DPA Message
The DPA "Messages" are error messages and are only present when
DPA ResultCode equals –1.
The HLR MOVER processes messages as shown in the following table:
DPA Identifier Value Notes XMA Column
DPA Message= Domain= The “part” of the record
that got the error
AUDIT.MESSAGECODE
as <domain>;<id>
Id= The error number
<text>= Error description AUDIT.RESULT
The word "TEXT" AUDIT.RULENAME
DPA ResultCode= –1 = fail
0 = success
AUDIT.OUTCOME
normalized by MOVER to
1 (success) or 3 (failure).
If the error text is more than 256 chars, more rows will be created to continue the
listing.
HLR Note 3 – DPA Property Set
The DPA Property Set is a comma-separated list of all the parameters that are being
set for the given DPA audit record. The HLR MOVER places the entire string in the
AUDIT.RESULT column in 256-character sets, so you may have from one to many
rows in XMA. All rows related to a single event will have the same
SESSION.SESSIONID and AUDIT.SEQNO values.
All rows that contain the Property Set will have "PARAM" placed in the
AUDIT.RULENAME
HLR Note 4 – Application Node ID
The DPA application Node ID is set during the creation of the HLR MOVER. The
parameter is stored and inserted by the MOVER in the SESSION.SESSIONNAME
column for every audit record processed by the MOVER.
There must be a separate HLR MOVER for each application Node ID.
