XYGATE Merged Audit
®
Reference Manual
Appendix G: Data Mapping
XYPRO Technology Corporation 260 Proprietary and Confidential
HLR Note 7
The entry in the AUDIT.RULENAME column indicates the type of data in the
AUDIT.RESULT column for the record.
AUDIT.RULENAME AUDIT.RESULT
TEXT Error description
PARAM Property String
FLAG Sensitive Param(s) only
HLR Audit Session Table
Column Type Record Contents
PARTITIONKEY
See General Note 1, pg 240.
numeric 4 MOVER Generated
RECORDSESSIONKEY timestamp MOVER Generated (unique timestamp
created when the first session row is
inserted into XMA database).
RECORDINSTALLKEY timestamp MOVER Generated
SESSIONID char 36 MOVER Generated (there is a session
per day; individual records on a given
day are assigned a Sequence Number.
See AUDIT.SEQNO).
FOUNDSESSIONSTART char 1
FOUNDSESSIONEND char 1
SESSIONNAME varchar 40 The HLR Application Node ID HLR
See HLR Note 4.
PROCESSTHREADID varchar 50
PROCESSTHREADID2 varchar 50
CLIENTPROGRAM varchar 50
ANCESTORPROCESSTHREADID varchar 50
IPADDRV46 char 46
DNSNAME varchar 100
CLIENTCURRDIR varchar 200 The full pathname of the target HLR
audit logs
SESSION.PRODUCTSYSTEM varchar 64 The NonStop server node where the
product that generated the event is
running.
SESSION.PRODUCTLOCATION varchar 200 The full pathname mask of the target
HLR audit logs. For example:
/app/hlr/NODEG/dpa*
