G7: EMS Data Mapping
EMS Audit Detail Table
Column Type Record Contents
PARTITIONKEY
See General Note 1, pg 240.
numeric(4) MOVER Generated
RECORDGMT See General Note 2.
timestamp ZEMS_TKN_GENTIME
GMTSEQNO char 2 MOVER Generated
RECORDLCT timestamp Calculated using
LCT(ZEMS_TKN_GENTIME) and
GMTOFFSET param
RECORDAUDITKEY timestamp MOVER Generated
RECORDSESSIONKEY timestamp MOVER Generated
SEQNO char 9 Generated
OUTCOME char 1 4 (=Unknown)
WARNINGMODE char 1
TESTMODE char 1 "N"
SEVERITY char 1 ZEMS_TKN_EMPHASIS (1 or 3)
ALERTED See General Note 4.
char 1
PRODUCTCODE char 10 MOVER Generated (EMS)
SUBJECTSYSTEM varchar 64 ZEMS_TKN_XSENDERID_PD
SUBJECTLOGIN varchar 40
See EMS Note 2.
SUBJECT_USERNUMBER_MAJOR char 8
See EMS Note 1.
SUBJECT_USERNUMBER_MINOR char 8
TARGET_USERNUMBER_MAJOR char 8
TARGET_USERNUMBER_MINOR char 8
TARGETLOGIN varchar 40 Is always same as SUBJECTLOGIN
OBJECTTYPE - Type of Object varchar 32 ZSPI_TKN_SSID
OBJECTNAME - Name of Object varchar 200 Objectname where parsed; that is,
BASE24/TELNET/LISTNER
OPERATION-Activity varchar 128 EMS-EVENT
TERMINAL varchar 64
See EMS Note 3.
MESSAGEID varchar 20 ZEMS_TKN_EVENTNUMBER
MESSAGECODE varchar 20
RULENAME varchar 50
RESULT varchar 256 EVENT TEXT -> will be split to fit
into multiple detail records
