XYGATE Merged Audit
®
Reference Manual
Appendix G: Data Mapping
XYPRO Technology Corporation 270 Proprietary and Confidential
G9: Measure Data Mapping
MEASURE Audit Detail Table
Column Type Record Contents
PARTITIONKEY
See General Note 1, pg 240.
numeric 4
RECORDGMT See General Note 2.
timestamp
GMTSEQNO char 2 MOVER Generated
RECORDLCT timestamp Creation time
RECORDAUDITKEY timestamp MOVER Generated
RECORDSESSIONKEY timestamp MOVER Generated
SEQNO char 9 System Generated
OUTCOME See General Note 3.
char 1
WARNINGMODE char 1
TESTMODE char 1 'N'
SEVERITY char 1
ALERTED See General Note 4.
char 1
PRODUCTCODE char 10 MEASURE
SUBJECTSYSTEM varchar 64 System of Process
SUBJECTLOGIN varchar 40 CAID translated (if possible)
SUBJECT_USERNUMBER_MAJOR char 8 CAID
SUBJECT_USERNUMBER_MINOR char 8 CAID
TARGET_USERNUMBER_MAJOR char 8
TARGET_USERNUMBER_MINOR char 8
TARGETLOGIN varchar 40
OBJECTTYPE - Type of Object varchar 32 "PROCESS"
OBJECTNAME - Name of Object varchar 200 Object file of Process
OPERATION-Activity varchar 128 "MEASURE"
TERMINAL varchar 64 Hometerm of Process
MESSAGEID varchar 20
MESSAGECODE varchar 20
RULENAME varchar 50 [node-name][$ or
$Processname].[CPU,PIN] or
UNKNOWN
RESULT varchar 256 [current-node-name.][$ or
$Processname][CPU,PIN]
Continued . . .
