XYGATE Merged Audit
®
Reference Manual
Appendix G: Data Mapping
XYPRO Technology Corporation 271 Proprietary and Confidential
MEASURE Audit Session Table
Column Type Record Contents
PARTITIONKEY
See General Note 1, pg 240.
numeric 4
RECORDSESSIONKEY timestamp MOVER Generated
RECORDINSTALLKEY timestamp MOVER Generated
SESSIONID char 36 System Generated (timestamp +
Unique ID)
FOUNDSESSIONSTART char 1
FOUNDSESSIONEND char 1
SESSIONNAME varchar 40
PROCESSTHREADID varchar 50 [current System name].[Processname
or CPU,PIN]
PROCESSTHREADID2 varchar 50
CLIENTPROGRAM varchar 50 MEASURE MOVER program file
ANCESTORPROCESSTHREADID varchar 50 Ancestor of MEASURE MOVER
Process
IPADDRV46 char 46
DNSNAME varchar 100
CLIENTCURRDIR varchar 200
