XYGATE Merged Audit
®
Reference Manual
Appendix G: Data Mapping
XYPRO Technology Corporation 273 Proprietary and Confidential
SFG Note 1
The data extracted from the SAFEGUARD audit logs is the same data extracted by
XSR
SFG Note 2
The SEQNO is set as follows:
• The primary record will be assigned a sequence number of 1.
• Subsequent records will be assigned a sequence number of 2.
• The actual value from the field rec-type will be in the MESSAGEID column.
• Refer to section 7.4, “Safeguard MessageIDs” on page 141 for more information on
Safeguard MESSAGEIDs.
SFG Note 3
Target User Fields are set as follows: If the OBJECTTYPE is equal to USER, ALIAS or
GROUP, the columns TARGET_USERNUMBER_MAJOR,
TARGET_USERNUMBER_MINOR and TARGETLOGIN will be updated.
SFG Note 4
When running reports for activity involving USER, ALIAS or GROUP, you will not see
REMOTEPASSWORD changes unless you also select the OBJECTTYPE
REMOTEPASSWORD.
SAFEGUARD Audit Session Table
Column Type Record Contents
PARTITIONKEY
See General Note 1, pg 240.
numeric 4
RECORDSESSIONKEY timestamp MOVER Generated
RECORDINSTALLKEY timestamp MOVER Generated
SESSIONID char 36 auditnumber-s
FOUNDSESSIONSTART char 1
FOUNDSESSIONEND char 1
SESSIONNAME varchar 40
PROCESSTHREADID varchar 50 Process name
PROCESSTHREADID2 varchar 50
CLIENTPROGRAM varchar 50
ANCESTORPROCESSTHREADID varchar 50
IPADDRV46 char 46
DNSNAME varchar 100
CLIENTCURRDIR varchar 200
