XYGATE Merged Audit
®
Reference Manual
Appendix G: Data Mapping
XYPRO Technology Corporation 275 Proprietary and Confidential
XAC Note 1
For XAC, the MESSAGECODE column shows whether or not the XAC command was
executed successfully.
If the field is blank, the OUTCOME is converted to a 1 (Success).
If there is any text in the field (that is, any error/denial messages), the OUTCOME is
converted to a 3 (Fail). The text of the message is placed in the RESULT column.
XAC Note 2
The RESULT column contains the text description associated with the value in the
OUTCOME column. For a list of the codes and associated values, refer to the
XYGATE Access Control (XAC) Reference Manual (HP part number 657928).
XAC Audit Session Table
Column Type XAC-I XAC-O XAC-C
XAC-E
PARTITIONKEY
See General Note 1, pg 240.
numeric 4 MOVER
Generated
RECORDSESSIONKEY timestamp MOVER
Generated
MOVER
Generated
RECORDINSTALLKEY timestamp MOVER
Generated
MOVER
Generated
SESSIONID char 36 Session Session
FOUNDSESSIONSTART char 1
FOUNDSESSIONEND char 1
SESSIONNAME varchar 40
PROCESSTHREADID varchar 50 Child-process-
descriptor
PROCESSTHREADID2 varchar 50 XAC-process-
descriptor
CLIENTPROGRAM varchar 50
ANCESTORPROCESSTHREADID varchar 50 Ancestor-process-
descriptor
IPADDRV46 char 46
DNSNAME varchar 100
CLIENTCURRDIR varchar 200 Volume-subvol
