XYGATE Merged Audit
®
Reference Manual
Appendix G: Data Mapping
XYPRO Technology Corporation 276 Proprietary and Confidential
G13: XYGATE Supported CMON (XCM) Data Mapping
XCM Audit Detail Table
Column Type XCM-S XCM-D XCM-E
PARTITIONKEY
See General Note 1, pg 240.
numeric 4
RECORDGMT See General Note 2.
timestamp
GMTSEQNO char 2 MOVER Generated
RECORDLCT timestamp Date-time
RECORDAUDITKEY timestamp MOVER Generated
RECORDSESSIONKEY timestamp MOVER Generated
SEQNO char 9 Sequence-number
OUTCOME See General Note 3.
char 1
See XCM Note 1.
WARNINGMODE char 1
TESTMODE char 1 'N'
SEVERITY char 1
ALERTED See General Note 4.
char 1
PRODUCTCODE char 10 MOVER Generated
SUBJECT_USERNUMBER_MAJOR char 8 Group-number
SUBJECT_USERNUMBER_MINOR char 8 User-number
TARGET_USERNUMBER_MAJOR char 8
TARGET_USERNUMBER_MINOR char 8
SUBJECTLOGIN varchar 40 Login-name
SUBJECTSYSTEM varchar 64 System of conf file
TARGETLOGIN varchar 40
OBJECTTYPE - Type of Object varchar 32
See XCM Note 2.
OBJECTNAME - Name of Object varchar 200
OPERATION-Activity varchar 128
See XCM Note 3.
TERMINAL varchar 64 Home-terminal
MESSAGEID varchar 20 Audit-type
MESSAGECODE varchar 20
See XCM Note 1.
RULENAME varchar 50 Encrypting (When activity-type =
PRELOGON)
RESULT varchar 256
