Appendix G: Data Mapping
XYPRO Technology Corporation 281 Proprietary and Confidential
G15: XYGATE Key Management (XKM) Data Mapping
XKM Audit Detail Table
Column Type Record Contents
PARTITIONKEY
See General Note 1, pg 240.
numeric 4
RECORDGMT See General Note 2.
timestamp
GMTSEQNO char 2 MOVER Generated
RECORDLCT timestamp Date-time
RECORDAUDITKEY timestamp MOVER Generated
RECORDSESSIONKEY timestamp MOVER Generated
SEQNO char 9 Sequence-number
OUTCOME See General Note 3.
char 1
See XKM Note 1.
WARNINGMODE char 1
TESTMODE char 1 'N'
SEVERITY char 1
ALERTED See General Note 4.
char 1
PRODUCTCODE char 10 MOVER Generated
SUBJECT_USERNUMBER_MAJOR char 8 Subject-Group-number
SUBJECT_USERNUMBER_MINOR char 8 Subject-User-number
TARGET_USERNUMBER_MAJOR char 8
TARGET_USERNUMBER_MINOR char 8
SUBJECTLOGIN varchar 40 Subject-Login-name
SUBJECTSYSTEM varchar 64 Subject-System
TARGETLOGIN varchar 40
OBJECTTYPE - Type of Object varchar 32 "KEY"
OBJECTNAME - Name of Object varchar 200 Keyid + Keysetid
OPERATION-Activity varchar 128 Operation
TERMINAL varchar 64
MESSAGEID varchar 20
MESSAGECODE varchar 20
See XKM Note 1.
RULENAME varchar 50
RESULT varchar 256 Result
XKM Note 1
For XKM, the possible MESSAGECODES are:
• 01 (Success) , which translates to an OUTCOME of 1 (Success)
• 00 (Fail), which translates to an OUTCOME of 3 (Fail)
