XYGATE Merged Audit
®
Reference Manual
Appendix G: Data Mapping
XYPRO Technology Corporation 283 Proprietary and Confidential
G16: XYGATE Process Control (XPC) Data Mapping
XPC Audit Detail Table
Column Type XPC-I XPC-E
XPC-S XPC-R
†
XPC-D
PARTITIONKEY
See General Note 1, pg 240.
numeric 4 MOVER Generated
RECORDGMT See General Note 2.
timestamp
GMTSEQNO char 2 MOVER Generated MOVER Generated
RECORDLCT timestamp Date-time Date-time
RECORDAUDITKEY timestamp MOVER Generated MOVER Generated
RECORDSESSIONKEY timestamp MOVER Generated MOVER Generated
SEQNO char 9 Sequence-number
OUTCOME See General Note 3.
char 1
See XPC Note 1. See XPC Note 1.
WARNINGMODE char 1
TESTMODE char 1 'N' 'N'
SEVERITY char 1
ALERTED See General Note 4.
char 1
PRODUCTCODE char 10 MOVER Generated MOVER Generated
SUBJECT_USERNUMBER_MAJOR char 8 Group-number
SUBJECT_USERNUMBER_MINOR char 8 User-number
TARGET_USERNUMBER_MAJOR char 8 (Process owner)
Group-number
TARGET_USERNUMBER_MINOR char 8 (Process owner)
User-number
SUBJECTLOGIN varchar 40 Login-name
SUBJECTSYSTEM varchar 64 Remote-System
TARGETLOGIN varchar 40 (Process owner)
Login-name
OBJECTTYPE - Type of Object varchar 32 “PROCESS” “PROCESS”
OBJECTNAME - Name of Object varchar 200 CPU-number,job-
number,priority,
external-Object,
Process-name,
ancestor
OPERATION-Activity varchar 128
See XPC Note 2.
TERMINAL varchar 64 Home-Terminal Home-Terminal
MESSAGEID varchar 20 Audit-type Audit-type
MESSAGECODE varchar 20
See XPC Note 1.
RULENAME varchar 50 PCGROUP Name
RESULT varchar 256
See XPC Note 3.
Comment
† Applicable to XPC starting with version 3.55.
