XYGATE Merged Audit
®
Reference Manual
Appendix G: Data Mapping
XYPRO Technology Corporation 284 Proprietary and Confidential
XPC Note 1
For XPC, an MESSAGECODE of "deny", causes an OUTCOME of 3. Otherwise, the
OUTCOME will be 1 (success).
XPC Note 2 (applicable to XPC 3.55 and up)
For MESSAGEID = “XPC-R” the value will be “XPC-REASON” for MESSAGEID =
“XPC-I”, “XPC-S”, and “XPC-E” the value will be the contents of the field
XPC-COMMAND.
XPC Note 3 (applicable to XPC 3.55 and up)
For MESSAGEID = “XPC-R” the value will be the contents of the field
XPC-COMMAND.
XPC Audit Session Table
Column Type XPC-I XPC-E
XPC-S XPC-R
†
XPC-D
PARTITIONKEY
See General Note 1, pg 240.
numeric 4 MOVER Generated
RECORDSESSIONKEY timestamp MOVER Generated MOVER
Generated
RECORDINSTALLKEY timestamp MOVER Generated MOVER
Generated
SESSIONID char 36 Session x(12)
FOUNDSESSIONSTART char 1
FOUNDSESSIONEND char 1
SESSIONNAME varchar 40
PROCESSTHREADID varchar 50 Process-Descriptor
PROCESSTHREADID2 varchar 50
CLIENTPROGRAM varchar 50
ANCESTORPROCESSTHREADID varchar 50 Ancestor-Process-
Descriptor
IPADDRV46 char 46
DNSNAME varchar 100
CLIENTCURRDIR varchar 200
† Applicable to XPC starting with version 3.55.
