XYGATE Merged Audit
®
Reference Manual
Appendix G: Data Mapping
XYPRO Technology Corporation 285 Proprietary and Confidential
G17: XYGATE Password Quality (XPQ) Data Mapping
XPQ Audit Detail Table
Column Type Record Contents
PARTITIONKEY
See General Note 1, pg 240.
numeric 4
RECORDGMT See General Note 2.
timestamp
GMTSEQNO char 2 MOVER Generated
RECORDLCT timestamp Date-time
RECORDAUDITKEY timestamp MOVER Generated
RECORDSESSIONKEY timestamp MOVER Generated
SEQNO char 9 Sequence-number
OUTCOME See General Note 3.
char 1
See XPQ Note 1.
WARNINGMODE char 1
TESTMODE char 1 'N'
SEVERITY char 1
ALERTED See General Note 4.
char 1
PRODUCTCODE char 10 MOVER Generated
SUBJECTSYSTEM varchar 64 System-name (if blank, then = the
system where the PQCONF resides)
SUBJECTLOGIN varchar 40 Subject-Login-name
SUBJECT_USERNUMBER_MAJOR char 8 Subject-Group-number
SUBJECT_USERNUMBER_MINOR char 8 Subject-User-number
TARGETLOGIN varchar 40 Target-Login-name
TARGET_USERNUMBER_MAJOR char 8 Target-Group-number
TARGET_USERNUMBER_MINOR char 8 Target-User-number
OBJECTTYPE - Type of Object varchar 32 Will always be "USER" or "ALIAS"
OBJECTNAME - Name of Object varchar 200 Target-Login-name
OPERATION-Activity varchar 128 "CHANGEPASSWORD"
TERMINAL varchar 64 Home-Terminal
MESSAGEID varchar 20
MESSAGECODE varchar 20
See XPQ Note 1.
RULENAME varchar 50 PQGROUP
RESULT varchar 256 Result
XPQ Note 1
For XPQ, the possible MESSAGECODES are:
• 00 (Success) , which translates to an OUTCOME of 1 (Success)
• 01 (Fail), which translates to an OUTCOME of 3 (Fail)
