XYGATE Merged Audit
®
Reference Manual
Appendix G: Data Mapping
XYPRO Technology Corporation 287 Proprietary and Confidential
G18: XYGATE Object Security (XOS) Data Mapping
XOS Audit Detail Table
Column Type Record Contents
PARTITIONKEY
See General Note 1, pg 240.
numeric 4
RECORDGMT See General Note 2.
timestamp
GMTSEQNO char 2 MOVER Generated
RECORDLCT timestamp Date-time
RECORDAUDITKEY timestamp MOVER Generated
RECORDSESSIONKEY timestamp MOVER Generated
SEQNO char 9 Sequence-number
OUTCOME See General Note 3.
char 1
See XOS Note 1.
WARNINGMODE char 1 Warning-mode flag
TESTMODE char 1 Test-flag
SEVERITY char 1
ALERTED See General Note 4.
char 1
PRODUCTCODE char 10 MOVER Generated
SUBJECTSYSTEM varchar 64 Subject-System (if blank then
System of conf file)
SUBJECTLOGIN varchar 40 Subject-Login-name
SUBJECT_USERNUMBER_MAJOR char 8 Subject-Group-number
SUBJECT_USERNUMBER_MINOR char 8 Subject-User-number
TARGETLOGIN varchar 40
TARGET_USERNUMBER_MAJOR char 8
TARGET_USERNUMBER_MINOR char 8
OBJECTTYPE - Type of Object varchar 32 Object-type
OBJECTNAME - Name of Object varchar 200
See XOS Note 2.
OPERATION-Activity varchar 128 request-type
TERMINAL varchar 64 Home-Terminal
MESSAGEID varchar 20
MESSAGECODE varchar 20
See XOS Note 1.
RULENAME varchar 50 Object group
RESULT varchar 256 Comment
