XYGATE Merged Audit
®
Reference Manual
Appendix G: Data Mapping
XYPRO Technology Corporation 291 Proprietary and Confidential
G20: XYGATE Combined Spoolcom Peruse Data Mapping (XSP)
XSP Audit Detail Table
Column Type Record Contents
PARTITIONKEY
See General Note 1, pg 240.
numeric 4
RECORDGMT See General Note 2.
timestamp
GMTSEQNO char 2 MOVER Generated
RECORDLCT timestamp Date-time-data
RECORDAUDITKEY timestamp MOVER Generated
RECORDSESSIONKEY timestamp MOVER Generated
SEQNO char 9
OUTCOME See General Note 3.
char 1 Outcome: N=3 Y=1
WARNINGMODE char 1
TESTMODE char 1 'N'
SEVERITY char 1
ALERTED See General Note 4.
char 1
PRODUCTCODE char 10 MOVER Generated
SUBJECT_USERNUMBER_MAJOR char 8 Group-number
SUBJECT_USERNUMBER_MINOR char 8 User-number
TARGET_USERNUMBER_MAJOR char 8
TARGET_USERNUMBER_MINOR char 8
SUBJECTLOGIN varchar 40 Login-name
SUBJECTSYSTEM varchar 64 System
TARGETLOGIN varchar 40
OBJECTTYPE - Type of Object varchar 32 “SPOOLER”
OBJECTNAME - Name of Object varchar 200 “SPOOLER OBJECT”
OPERATION-Activity varchar 128 Command
TERMINAL varchar 64 Terminal
MESSAGEID varchar 20 XSP-I/XSP-D/XSP-E
MESSAGECODE varchar 20 Outcome
RULENAME varchar 50
RESULT varchar 256 Outcome
