XYGATE Merged Audit
®
Reference Manual
Chapter 1. Installing XMA
XYPRO Technology Corporation 8 Proprietary and Confidential
SEL LOCATION VERSION OWNER AVAILABILITY
--- ----------------- ------- ----------------- ------------
1) $SYSTEM.XYGATEMA 1.70 SUPER.SUPER Not Available
2) $DATA1.XYGATEMA 1.54 XMA.OWNER Not Available
5) $ARC.XYGATEMA 1.54 XYPRO.HARRIET Not Available
P) Prompt for new location Available
Enter available selection:
If this is a new install, one of the following will be true:
no environments will be located or
no available environments will be located or
a new environment needs to be installed.
If existing environments are located, select the P option to install a new environment.
Enter available selection: P
Referring to Table 1 values, enter a Volume name or accept the default volume
displayed by the prompt.
Enter XMA volume <$MYVOL>?
Then enter a subvolume name at the prompt. It would be helpful to identify it as the
XMA subvolume using a name such as XYGATEMA or XMAPROD, etc.
Enter XMA subvol? <XYGATEXM> ?
The AutoInstall script will attempt to locate any installed XTR environments and will
display these located environments as shown below.
-------------------------------------------------------------------------------
The XYGATE Transaction Router (XTR) is used to provide communication between
XYGATE GUI products and their HP NonStop server counterparts. The transaction
router provides the connection between the PC and the NonStop host via a LISTNER.
One installation of XTR can be utilized by all the XYGATE GUI products, so you
only need to configure one port on each host even if you are using more than one
XYGATE GUI product.
Discovering XTR ($*.*) ...
Discovery complete.
SEL LOCATION VERSION OWNER AVAILABILITY
--- ----------------- ------- --------------- ------------
1) $SYSTEM.TR152 1.52 QA.JOE Not Available
2) $SYSTEM.XYGATETR 1.53 SUPER.SUPER Not Available
3) $DATA1.XYGATETR 1.53 XMA.OWNER Not Available
5) $DATAA.XYGATETR 1.52 XYPRO.TRACY Not Available
P) Prompt for new location Available
