XYGATE Merged Audit
®
Reference Manual
Appendix G: Data Mapping
XYPRO Technology Corporation 297 Proprietary and Confidential
G23: XYGATE Compliance PRO (XSW) Data Mapping
XSW Audit Detail Table
Column Type Record Contents
PARTITIONKEY
See General Note 1, pg 240.
numeric 4
RECORDGMT See General Note 2.
timestamp
GMTSEQNO char 2 MOVER Generated
RECORDLCT timestamp Date-time-data
RECORDAUDITKEY timestamp MOVER Generated
RECORDSESSIONKEY timestamp MOVER Generated
SEQNO char 9 Sequence-number
OUTCOME See General Note 3.
char 1
outcome
WARNINGMODE char 1
TESTMODE char 1
SEVERITY char 1
ALERTED See General Note 4.
char 1
PRODUCTCODE char 10 MOVER Generated
SUBJECTSYSTEM varchar 64 conn-system
SUBJECTLOGIN varchar 40 Subject-login-name
SUBJECT_USERNUMBER_MAJOR char 8 Subject-group number
SUBJECT_USERNUMBER_MINOR char 8 Subject-user-number
TARGETLOGIN varchar 40 Client-logon
TARGET_USERNUMBER_MAJOR char 8
TARGET_USERNUMBER_MINOR char 8
OBJECTTYPE - Type of Object varchar 32 Objecttype
OBJECTNAME - Name of Object varchar 200 Objectname
OPERATION-Activity varchar 128 Operation
TERMINAL varchar 64
MESSAGEID varchar 20 Work-system
MESSAGECODE varchar 20
outcome
RULENAME varchar 50 Coll-name
RESULT varchar 256 result
