XYGATE Merged Audit
®
Reference Manual
Chapter 1. Installing XMA
XYPRO Technology Corporation 11 Proprietary and Confidential
SUPER.SUPER, and
RUN $MYVOL.IXYPROMA.LICENSE
You may continue when this has been done.
If you decide not to continue, the next time the wizard is run, it will
continue here, where you last stopped.
Are you ready to continue ?
Do not answer the prompt yet.
Start a separate TACL session using a SUPER logon, and perform the necessary
licensing tasks as shown in the Example below.
Example:
TACL> RUN $MYVOL.IXYPROMA.LICENSE
Licensing $MYVOL.XYGATEMA.XYGATESR
Licensing $MYVOL.XYGATEMA.ADOPT
Licensing $MYVOL.XYGATEMA.USERINFO
TACL> Logoff as the SUPER.SUPER or SUPER alias.
When you complete the licensing tasks, answer Y to the prompt to continue.
Are you ready to continue ? Y
Establishing product locations ...
Product locations established.
Performing verifications ...
Verifications complete.
Installing products:
Install of products complete.
Performing products syntax check ...
Products syntax check complete.
Starting XMA ...
XMA started.
Verifying XMA is listed in XTR TRACL file ...
Done verifying XMA is listed in XTR TRACL file.
XYGATE GUIs use a LISTNER process to connect to the host.
You may choose to have a XYGATE LISTNER started now.
WARNING: The XYGATE LISTNER is intended for testing your XYGATE/TR configuration.
This XYGATE LISTNER process may disappear. To assign a permanent LISTNER, add the
following to $SYSTEM.ZTCPIP.PORTCONF and restart the HP LISTNER.
WARNING: The start listner macro is intended for testing your XYGATE/TR
configuration. For production usage, you must use the HP Listner by making
entries in your PORTCONF.
The port connection for the GUI/PC modules can be permanently set up to the
system’s PORTCONF file using the following information. If the port is defined in this
manner, it will be restarted each time the system is cold-loaded or TCP/IP is re-started.
11211 $MYVOL.XYGATETR.XYGATETR -SERVER
