XYGATE Merged Audit
®
Reference Manual
Chapter 1. Installing XMA
XYPRO Technology Corporation 13 Proprietary and Confidential
As of version 1.95, XMA accommodates IPV6 addresses. If you already have the
ArcSight log adapter installed and upgrade XMA, you will also have to upgrade the log
adapter by following the installation instructions below.
1.3.2 Installing the Adapters
You should have the following information available for the adapter installation:
Prompt Description
Selection
If more than one adapter is available for installation
in the XYGATE Merged Audit product installation
location, you will be prompted to select which
adapter to install.
If only one adapter is available for installation, that
adapter is automatically selected; otherwise, the
only available adapter is automatically selected.
Enter SIEM Device IP address
<xxx.xxx.xxx.xxx>?
This is the IP address of the SIEM device where
the XYGATE Merged Audit product should “syslog”
messages specifically formatted for the SIEM
device.
Enter TCP/IP process name
<$ZTCP2>?
This is the name of the TCP/IP process through
which the SIEM device IP address is accessible.
Pressing Enter at this prompt accepts the default
value enclosed by the angle brackets < >.
The default value is the value for the define
=TCPIP^PROCESS^NAME for the current TACL
process, or if none exists, the transport process for
the TELSERV process from which the installation
procedure is being executed.
Enter TCP/IP process name for
remote node \XYS7000 <$ZTC0>?
If remote nodes exist for the XYGATE Merged
Audit installation, you will have to enter the name
of the TCP/IP process through which the SIEM
device IP address is accessible for each remote
node.
The default value is the value for the define
=TCPIP^PROCESS^NAME for the current TACL
process, or if none exists, the transport process for
the TELSERV process from which the installation
procedure is being executed.
If the adapter to be installed was obtained separate from the XYGATE Merged Audit
product software, then follow the installation instructions that came with the adapter.
If the adapter to be installed came with the XYGATE Merged Audit product, then
volume to the installation location of the XYGATE Merged Audit product and run LAF
from TACL. The following is a sample dialog.
