XYGATE Merged Audit
®
Reference Manual
Chapter 1. Installing XMA
XYPRO Technology Corporation 17 Proprietary and Confidential
Enter available selection: 3
Updating config ...
Config updated.
The AutoInstall script will attempt to locate any already installed XTR environments
and display these located environments as shown below.
-------------------------------------------------------------------------------
The XYGATE Transaction Router (XTR) is used to provide communication between
XYGATE GUI products and their HP NonStop server counterparts. The transaction
router provides the connection between the PC and the NonStop host via a LISTNER.
One installation of XTR can be utilized by all the XYGATE GUI products, so you
only need to configure one port on each host even if you are using more than one
XYGATE GUI product.
Discovering XTR ($*.*) ...
Discovery complete.
SEL LOCATION VERSION OWNER AVAILABILITY
--- ----------------- ------- --------------- ------------
1) $SYSTEM.TR152 1.52 QA.JOE Not Available
2) $SYSTEM.XYGATETR 1.53 SUPER.SUPER Not Available
3) $DATA1.XYGATETR 1.53 XMA.OWNER Not Available
4) $MYVOL.XYGATETR 1.53 MY.OWNER Available
5) $DATAA.XYGATETR 1.52 XYPRO.TRACY Not Available
P) Prompt for new location Available
If this is an upgrade, choose the number of the existing environment to be upgraded.
Only environments that are owned by your userid are available to be upgraded. Other
environments are shown for information only.
Enter available selection: 4
Updating config ...
Config updated.
Product locations established.
Performing verifications ...
If the installed software product version is the same or newer than the version being
installed by the script, the upgrade of that product will be skipped.
Available version of XTR is not higher than the
installed version. XTR installation skipped.
Available version of XMA is not higher than the
installed version. XMA installation skipped.
Verifying XMA is listed in XTR TRACL file ...
Done verifying XMA is listed in XTR TRACL file.
If the installed software is already at an older version, the script will attempt any
upgrade products.
