XYGATE Merged Audit
®
Reference Manual
Chapter 1. Installing XMA
XYPRO Technology Corporation 18 Proprietary and Confidential
The AutoInstall script will attempt to verify the selected locations. Any old installation
staging locations may have to be purged manually.
Files already exist in the location where the XTR product unpacks to:
$MYVOL.P46DSDST
You must purge the files on this subvol before continuing.
Are you ready to continue <Y/N>?
Do not answer the prompt yet.
You may or may not receive the above prompt. If you do, you must purge or rename
the P46DSDST subvolume now.
Start a separate TACL session, and execute the purge or rename functions as shown
in the Example below.
Example:
TACL> FUP PURGE $MYVOL.P46DSDST.* !
- or -
TACL> FUP RENAME $MYVOL.P46DSDST.*, $MYVOL.O46DSDST.*
When you complete the purge or rename function, answer Y to the prompt to continue.
Are you ready to continue <Y/N>? Y
Unpaking products:
Unpaking XTRBIN ...
Unpak of XTRBIN complete.
Unpaking products complete.
Installing products:
Verifying the system catalog can be written to ...
Verified the system catalog can be written to.
If the installed software is older than the current version, the script will notify you and
perform the upgrade. Upgrading the XTR software requires licensing of one of the
installation programs to perform this function.
Comparing installed version of XTR to available version ...
A higher version of XTR was found.
XTR will be upgraded.
$MYVOL.P46DSDST.IADOPTN4 is not licensed.
Cannot continue until these files are licensed by SUPER.SUPER.
Please go to another TACL session, logon as SUPER.SUPER, and license these
files. You may continue when this has been done.
If you decide not to continue, the next time the wizard is run, the wizard
will continue where you last stopped.
To license these files, enter the following commands:
FUP LICENSE $MYVOL.P46DSDST.IADOPTN4
