XYGATE Merged Audit
®
Reference Manual
Chapter 1. Installing XMA
XYPRO Technology Corporation 23 Proprietary and Confidential
This will remove ALL files from the following locations, even if the
product was not recently installed or upgraded:
XTR Installed files on \N1.$MYVOL.XYGATETR
XTR Unpak'd files on \N1.$MYVOL.P46DSDST
XMA Installed files on \N1.$MYVOL.XYGATEMA
XMA Tables on \N1.$MYVOL.XMADAT
XMA Catalog on \N1.$MYVOL.XMACAT
XMA Pathway files on \N1.$MYVOL.XMAPW
Are you ready to continue <Y/N>?
If you wish to uninstall these XMA and XTR environments, enter Y to continue. The
uninstall process takes a few minutes to complete.
Are you ready to continue <Y/N>? Y
Working ...
Detaching segment ...
Removing XTR Installed files on \N1.$MYVOL.XYGATETR ...
Removing XTR Unpak'd files on \N1.$MYVOL.P46DSDST ...
Removing XMA Installed files on \N1.$MYVOL.XYGATEMA ...
Removing XMA Tables on \N1.$MYVOL.XMADAT ...
Removing XMA Catalog on \N1.$MYVOL.XMACAT ...
Removing XMA Pathway files on \N1.$MYVOL.XMAPW ...
Checking results ...
Done.
1.6.2 Installing the GUI/PC Products
If you are installing XMA from an HP SUT distribution, the distributed subvolume
(DSV) will contain binary files for the GUI/PC products that you can optionally install.
The GUI/PC products included with the XMA product will perform the following tasks:
• Pre-formatted and custom reports on the SQL audit repository (IXRGEXE)
• Perform configuration changes to the environment (IXCFEXE)
• A GUI view of alerts and monitoring of the audited information (IXEMEXE)
• A GUI Information support tool (IXGIEXE)
• Display Online help information for XYGATE products (IXOHEXE)
Note: Refer to the XYGATE User Guides for each product and the considerations and
instructions at the beginning of this chapter for installation on your PC.
1. Locate the installation staging which was used for the install or upgrade function,
and set the default volume to that location.
Syntax:
TACL> VOLUME [$NEWVOL].IXYPROMA
Example:
TACL> VOLUME $MYVOL.IXYPROMA
